SEESII Nanovna-H Vector Network Analyzer,Upgraded HW3.6 10KHz-1.5GHz MF HF VHF UHF Antenna Analyzer, Measuring S Parameters, Voltage Standing Wave Ratio,Phase,Delay,Smith Chart,Support Data Storage
Product details
| Management number | 208583932 | Release Date | 2026/03/22 | List Price | $18.04 | Model Number | 208583932 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Upgraded Nanovna-H HW3.6: SeeSii Nanovna-H Vector Network Analyzer is developed by Hugen. With latest 3.6 version,10KHz-1.5GHz measure range,2.8 inch LCD touchscreen,mini and portable design.This Antenna Analyzer is provides outstanding vector network measurement capabilities and perfect for evaluating antenna resonance and SWR.It is a very mini handy & smart analyzer for electronics engineer, amateur radio operators or radio diy amateurs
- Improved Frequency Algorithm: The enhanced frequency algorithm uses the odd harmonic extension of the si5351, supporting measurements up to 1.5GHz. The metal shield reduces external interference, improving accuracy. The si5351 direct output offers 70dB dynamic range (50K-300MHz), 60dB (300M-900MHz), and 40dB (900M-1.5GHz). The default firmware supports antenna performance measurement
- Multi TX/RX Function: The default firmware is mainly used for antenna performance measurement. The TX/RX method can measure the complete S11/S21 parameters (need to manually replace the transceiver port wiring)
- Android and PC Software Control: The NanoVNA analyzer uses NanoVNASaver software, which connects to the device, extracts data, and saves it in Touchstone format for display on a computer
- Built-in Micro-SD Port & Time Display: The lastest antenna analyzer with MicroSD card port,so you can save field test data or screens to a MicroSD card at any time,support up to 32GB memory card. (Not include in the pacakge).In addition, different from old version NanoVNAs, the date and time can be customized, which is convenient for you to further record and save data..The default firmware main function is used for antenna performance measurement
- Abundant Accessories: Come with 1x NanoVNA-H host, 2x 30cm SMA Male to Male RG174 RF Cable, 1x SMA Female to Female Connector,1x SMA SHORT,OPEN &LOAD simple calibration kit,1x USB Type-C Data Cable, 1 x USB-C to USB-C Line, 1x Lanyard and touch plectrum. All the accessories are packaged in a sophisticated box.This is nice vna analyzer for your own use or as a gift for your friend
| Batteries | 1 Lithium Ion batteries required. (included) |
|---|---|
| Manufacturer | Seesii |
| Item model number | NanoVNA-H |
| Package Dimensions | 5.31 x 4.02 x 2.13 inches; 7.05 ounces |
