JMT USR-TCP232-306 Serial Port RS232/RS485/RS422 to TCP Converter with DHCP and Built-in Webpage with 5V 3A Power Supply (2PCS)
Product details
| Management number | 216079800 | Release Date | 2026/04/19 | List Price | $28.64 | Model Number | 216079800 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
- Ethernet to serial converters USR-TCP232-306 support both interfaces RS232 and RS485, but can only use one at one time. Simple configuration and easy to use.
- Auto-MDI/MDIX, RJ45 port with 10/100Mbps; Work mode: Compatible-with-TCP Server, Compatible-with-TCP Client, UDP Client, UDP Server, HTTPD Client ; Baud rate of serial port can be configured from 600 bps to 230.4 Kbps, supports check bit of none, odd, even, mark and space
- Heartbeat package mechanism to ensure connection is reliable, put an end to dead link; User-defined registration package mechanism, check connection status and use as custom packet header; Under Compatible-with-TCP Server Mode, the connection number with client can be randomly set from 1 to 16, default number is 4.
- IP has been connected can be shown according to connectiong with calculating send / recceive dat. When connection number reaches a maximun, the new connection is kicked off the old one can be configured by user;Parameters can be configured by built-in webpage, AT command, serial port procotol and network procotol. Setting procotol is avaliable to integrate into user?s software.
- Compatible with TCP client short connection function, user-defined the disconnected time.Device restart if no data transmission or timeout. User-defined the restart time. If data buffer needs to clear configuration before Compatible-with-TCP connection establishment;Supports DHCP, automatically obtain an IP address and query IP address via serial setting protocol.The global unique MAC address, user-defined MAC address.
